Undermount SERIES ISSWT 120 -160

Undermount

SERIES ISSWT 120 -160

Vertical single coil storage indirect cylinders are designed to be combined with any wall-hung boiler for the production of large quantities of hot water despite space restrictions.

The rectangular shape can be fitted as an undermount indirect cylinder. The coloured PVC coating enhances its appearance and protects it against possible damage during assembly and normal use. In addition, the product is designed so that it can be completely dismantled for recycling and/or the disposal of its components. Ideal for domestic use.

Declaration of Conformity

Energy Label

User Manual

Technical Sheet

Description

Steel tank, glass-lined “Blue Glass 4753” using flow-coating method 850°C, WRAS (BS6920-1) certified
ø 84 mm top inspection flange complete with counter-flange and probe sheath (Tr)
Corrosion-proof magnesium anode
Drain tap
Lowered coil for the maximum heat exchange process and to reduce the formation of limescale

Outlet and recirculation fittings
Hydraulic fittings installed in the upper part to facilitate the connection with a wall-hung boiler
Self-extinguishing and very thick high-density (EPS) polystyrene shell
External soft plastic coating (PVC), white RAL 9010
Adjustable feet for floor standing
Stored water temperature indicator
